Refactoring: Change unidirectional association to bidirectional

Many times, when coding, we use different data structures: stacks, queues, trees.

These structures have the elements linked between them, allowing parsing and searching.

Usually when we start coding such a structure we consider a unidirectional link between the elements, mostly to save memory.

Let's consider the following class:

Refactoring - Introduce new method

Consider you have a function that perform an activity on an object a certain class in multiple places across the class and the project.

Sometimes, it makes sense to add that functionality directly to the class.

Swift makes this very simple using extensions. They allow to add new functionality to an existing class, structure or enumeration even if you do not have access to its code.

Let's take the following example:

Refactoring - Inline temp

This refactoring is the reverse of the Explaining variable.

You added a new variable to make the code clearer. But after few changes the variable is not really useful.

Consider the following piece of code:

Refactoring in Swift - Inline class

This method of refactoring is just the opposite of Extract class.

Think of a class that became so small and so unused that it does not justify its existence.

Consider an application that has the following classes:

Refactoring in Swift - Replace Array with an Object

This refactoring applies to the case when different kinds of information are stored in an array.

For example, we have an array storing the first name, the last name and the age as follows:

Refactoring in Swift - substitute algorithm

In previous post (Simplify nested conditionals with returns) we arrived at the following code:

func bonusForSalary(salary:Float, numberOfKids: Int) -> Float {



    if numberOfKids == 0 {

        return salary * 0.2

    }

    if numberOfKids == 1 {

        return salary * 0.3

    }

    if numberOfKids == 2 {

        return salary * 0.4

    }

    if numberOfKids == 3 {

        return salary * 0.5

    }

    return salary * 0.6

}

Refactoring in Swift - simplify nested conditionals with returns

Consider the case when a function needs to calculate the result using a complicated set of logic statements based on the input.

We would need to store the result in a variable and return it at the end. Or do we?

Refactoring in Swift - Extract class

According to the Single Responsibility Principle, one class should do one thing. Also it needs to know the least amount of information to do its job.

In time though, all the classes evolve by accumulating more and more properties and functions. That is why refactoring is needed to simplify them and restrict their area of action.

One of the methods is extract class method. When a class becomes too big, extract part of it as another class.

Consider the following User class:

Refactoring in Swift - Move method

"Yesterday, I froze some water."

While this is possible (I took some water, put it in a container, and in the freezer), it sounds funny. Of course, I did not froze the water, because I don't do that. I am not a freezer. The freezer freezes water, that is why it is called a freezer.

"As it snowed today, I will blow the snow."

Learn how to build apps

Are you interested in learning how to build apps for iPhone and iPad?

You don’t know where to start?

Let me know and I will help you to the best of my knowledge and my time.

There is no cost involved.

I love building apps and if I can help you get started and get you to love it too,
that will be enough payment.

Art creator page

Refactoring in Swift - move field

Imagine classes as families. They should hold inside only what makes sense.

One does not invite neighbours to live with them, does he? Invite them to visit, maybe, but move in, no way!

So are classes. They should hold only the fields that make sense.

Refactoring in Swift - Replace method with method object

Let's continue with the same game as in Explaining Variable refactoring method.

We still have the two ships, each of them defined as a rectangle (CGRect) but today they start shooting at each other.

So other than the ships we have two projectiles, also defined as rectangles.

We also have a number of functions to manage the game.

Refactoring in Swift - explaining variable

Swift theory

In case you are not a Swift programmer, CGRect is a structure that defines a rectangle by setting its origin and size.

For example, a CGRect of value (10, 20, 100, 150) represents a rectangle with origin at x = 10 and y = 20 and with a size of width = 100 and height = 150.


Refactoring

Now, let's build a game. Or at least a very small part of the game.

Refactoring in Swift - Inline function

Refactoring by inline function is the opposite of the Extract function we analyzed in a previous post.

In this case, a function is so short and it is used only in one or two spots that is it not worth having it separately.

This refactoring is done by removing the function and replacing each call with its content.

Refactoring in Swift - Extract function

The simplest method of refactoring and maybe the most used is performed by moving the code around.

We can move it from one function to another, from one class to another or create a new entity, in our case, a new function.

Consider the following function to validate three fields: first name, last name and address. Each variable needs to have a value.

var firstName, lastName, address : String?

firstName = "John"

lastName = "Smith"

address = "20 New Way St."

func validateForm() -> Bool {

    var valid = true



    if (firstName == nil) || (firstName!.characters.count == 0) {

        valid = false

    }

    if (lastName == nil) || (lastName!.characters.count == 0) {

        valid = false

    }

    if (address == nil) || (lastName!.characters.count == 0) {

        valid = false

    }

    return valid

}

A Little Architecture by Uncle Bob

I want to become a Software Architect.

That's a fine goal for a young software developer.

I want to lead a team and make all the important decisions about databases and frameworks and web-servers and all that stuff.

Oh. Well, then you don't want to become a Software Architect after all.
read more

Refactoring in Swift

Definition

Refactoring is the activity of cleaning the code, improving the design, after the code is written.

Refactoring is not changing the functionality of the code. If it does, it is called maintenance. [Thank you Max]

You can say that it is corresponding to the design phase, but after some piece of code was written.

While a developer can plan for the code to be nicely written, in time, the code gets messier so cleaning is required.

Just like the house cleaning, the more often the code is cleaned, the easier and more effective it is.

Refactoring does not bring any benefit right away. The functionality is not changed during this activity so there is no change for the user. The real benefit is when new features are added.

We’ll start today a series of refactoring tips in Swift, most of them adapted/stolen from Martin Fowler’s “Refactoring - Improving the design of existing code” book.
